7. Daily Inspection and Maintenance
-53-
7.1.2.2 Check Items on the Image
Main
unit
Check that the chin rest
moves smoothly up and down
when the CHIN REST switch
is pressed.
Pass/
Fail
Pass/
Fail
Pass/
Fail
Contact your sales representative
or local Canon dealer if there are
any problems.
Loca
tio
n
Inspection
Result
Remedy Month
Day
Month
Day
Month
Day
Lo
ca
tio
n
Inspection
Result
Remedy Month
Day
Month
Day
Month
Day
Foreign
objec
t on image
Place a sheet of paper in front
of the objective lens and take
a test image in the following
conditions.
Conditions
Flash intensity: Standard pos.
Diopter comp. lever: 0
Focus knob: Turn the knob on
the right (viewed from you)
all the way clockwise.
Then check that there is no
foreign matter present on the
image that can affect image
readings.
Pass/
Fail
Pass/
Fail
Pass/
Fail
Clean the objective lens (see
page 57). If you cannot remove
the foreign matter on the image,
stop using the retinal camera and
contact your sales representative
or local Canon dealer.
