ESC i V 2D bar code PDF417
[ASCII] ESC i V or v Data
[Decimal] 27 105 86 or 118 Data
[Hexadecimal] 1B 69 56 or 76 Data
・ Format
ESC i V or v [Parameters] [Bar code data]
\\\
1 2 3
① Parameters
Unlike with 1D bar codes, it is necessary to specify all parameters from the top down.
If a value other than those listed is entered for a parameter, that parameter is set to its
default value.
77
1. Cell size
[Decimal 1 byte] 3
[Decimal 1 byte] 4
[Decimal 1 byte] 5
[Decimal 1 byte] 6
[Decimal 1 byte] 8
[Decimal 1 byte] 10 Sets the dot size per cell side.
Prints 3 dots per cell side. (default value)
Prints 4 dots per cell side.
Prints 5 dots per cell side.
Prints 6 dots per cell side.
Prints 8 dots per cell side.
Prints 10 dots per cell side.
2. Symbol type
[Decimal 1 byte] 0
[Decimal 1 byte] 1
[Decimal 1 byte] 2
[Decimal 1 byte] 3
Standard (default value)
Truncate
MicroPDF417 standard
MicroPDF417 Code128 emulation
3. Data input method
[Decimal 1 byte] 0
[Decimal 1 byte] 1
Auto input (default value)
Binary input
4. Error correction capacity
and type
[Decimal 1 byte] 0
[Decimal 1 byte] 1
Level input setting (default value)
Percentage input setting
5. Error correction capacity
and value Level input
selection
[Decimal 2 bytes] 0–8
Percentage input selection
[Decimal 2 bytes] 0–400
Inputs the level. (The default value is 0.)
Inputs the percentage. (The default value is 10.)
6. Symbol size X specification
[Decimal 1 byte] 0
[Decimal 1 byte] 1–30
*0 and 1–4 with MicroPDF417
Auto setting (default value)
Manual setting
7. Symbol size Y specification
[Decimal 1 byte] 0
[Decimal 1 byte] 3–90
*0 and 4–44 with MicroPDF417
Auto setting (default value)
Manual setting
