・ With linkage. [Three partitions] (The parity for the character string “123456789" is
0x31.)
ESC i Q 0x04 0x02 0x01 0x01 0x03 0x31 0x02 0x00 “123”
\\\
ESC i Q 0x04 0x02 0x01 0x02 0x03 0x31 0x02 0x00 “456”
\\\
ESC i Q 0x04 0x02 0x01 0x03 0x03 0x31 0x02 0x00 “789”
\\\
2
[Bar code data]: Bar code data
When manual input is selected in 8 (data input method of the parameters), the bar code
data must be preceded with one of the following single-byte alphanumeric characters.
Number input N or n
Alphanumeric input A or a
Kanji input K or k
Binary input B or b + 4 digits of numbers
Specify numbers of binary character that is input the “4 digits numbers”
For example, if you input 12 characters, it should be;
B 0012 (0x30,0x30,0x31,0x32)
1. Kanji
ESC i Q [other parameters] 1 K kanji input
\\\
2. Alphanumeric input
ESC i Q [other parameters] 1 A012345678aBcDe
\\\
3. Binary input
ESC i Q [other parameters] 1 B0005#### \\\
The number of bar code data items that can be input depends on the model type and the
input type.
Model 1: 707 English alphanumeric characters, 1167 numbers, 486 binary bytes, 299 kanji
Model 2: 4296 English alphanumeric characters, 7089 numbers, 2953 binary bytes, 1817 kanji
Micro QR: 21 English alphanumeric characters, 35 numbers, 15 binary bytes, 9 kanji
Note:The numbers shown here is for high-density Level L 7% of Error correction level. If
you specify them on more than standard lebel, the number may decrease. And, even if you
Specify then on high-density level, it may decrease because of the treatment of
compression.
3
\\\
: End of bar code
75
Three back slashes are necessary for end of 2D bar code.
