Brother TD-4100N - Manual (Page 55)

ESC (V Specify absolute vertical position
[ASCII] ESC （ V nL nH mL mH
[Decimal] 27 40 86 nL nH mL mH
[Hexadecimal] 1B 28 56 nL nH mL mH
[Parameters] nL=2
nH=0
0≤mL≤255
0≤mH≤127
[Description]
・ Specifies the vertical print position as an absolute position from the top margin position.
Vertical position = mL + mH * 256 + top margin
・ The absolute vertical position is measured from the top margin position at the time.
・ If a position exceeding the bottom margin is specified, printing starts.
・ There is no restriction on the amount of movement back (upward) from the current
position.
・ With left alignment, the print position for the next line is the end position of the current
line. (The horizontal position does not move to the left margin.)
With right alignment and center alignment, the horizontal position moves to the beginning
of the line.
・ Automatic cancellation of double-width characters specified with SO or ESC SO is
cancelled.
55
