Print position
The print position is the standard position for printing characters, bitmaps, and bar codes.
There is a horizontal print position and vertical print position, which are the reference points
for vertical position movement and horizontal position movement.
Characters are arranged with their top edges aligned with the print position.
The baseline of each character is the bottom edge of the character, regardless of size, font,
etc.
Print position
A
Baseline position
All characters on a single line are printed at baseline positions that are the same for each
character.
When characters of different heights are mixed together, they are aligned with the baseline
of the tallest character on the line.
Print position
A
Underlines are drawn 4 dots below the baseline position.
A
A
Baseline position
15
