USING FUNCTIONS BY CONNECTING THE ACCESSORY TO THE MACHINE
G
ettin
g R
ea
d
y
Basic operations B-63
B
1
Using USB Media or Embroidery
Card Reader/USB Card Writer
Module*
* If you have purchased the PE-DESIGN Ver5 or later,
PE-DESIGN NEXT, PE-DESIGN Lite, PED-BASIC or
PE-DESIGN PLUS, you can plug the included USB
card writer module into the machine as an
embroidery card reader, and recall patterns.
a USB port for mouse / media
b USB media
a USB port for mouse / media
b Embroidery card Reader/USB card writer module*
Connecting the Machine to the
Computer
Using the included USB cable, the sewing machine
can be connected to your computer.
a USB port for computer
b USB cable connector
USING FUNCTIONS BY CONNECTING THE
ACCESSORY TO THE MACHINE
Note
• Use only an embroidery card reader
designed for this machine. Using an
unauthorized embroidery card reader may
cause your machine to operate incorrectly.
• Embroidery patterns cannot be saved from
the machine to an embroidery card inserted
into a connected USB card writer module.
Memo
• USB media is widely used, however some
USB media may not be usable with this
machine. Please visit our website for more
details.
• Depending on the type of USB media being
used, either directly plug the USB device
into the machine’s USB port or plug the
USB media Reader/Writer into the
machine’s USB port.
Note
• The connectors on the USB cable can only
be inserted into a port in one direction. If it
is difficult to insert the connector, do not
insert it with force. Check the orientation of
the connector.
• For details on the position of the USB port
on the computer (or USB hub), refer to the
instruction manual for the corresponding
equipment.
