SEWING THE STITCHES
S-60
c
Set the fabric so that the pocket moves
toward you during sewing.
d
Check the first needle drop point and lower
the presser foot.
a 2 mm (approx. 1/16 inch)
e
Lower the buttonhole lever so that it is
positioned behind the metal bracket on the
buttonhole foot.
a Metal bracket
f
Gently hold the end of the upper thread and
begin sewing.
→ When sewing is completed, the machine will sew
reinforcement stitches and stop automatically.
Memo
• Bar tacks can be between 5 mm (approx.
3/16 inch) and 28 mm (approx. 1-1/16
inches). Bar tacks are usually between 5
mm (approx. 3/16 inch) and 10 mm (approx.
3/8 inch).
Note
• Pass the thread underneath the presser
foot.
• Slide the outside frame of the buttonhole
foot backward as far as possible as shown
in the illustration, making sure that there is
no gap behind the part of the foot marked
“A”. If the buttonhole foot is not slid back as
far as possible, the bar tack will not be sewn
to the correct size.
