MAKING EMBROIDERY ADJUSTMENTS
Em
br
oide
ry
Embroidering E-35
E
1
Changing the “Embroidery Frame
Display”
a
Press .
b
In the “Embroidery Frame Display”, use
to change the embroidery frame display
mode.
* There are 16 choices.
* For the optional embroidery frame.
a Extra large frame embroidering area
30 cm × 18 cm (12 inches × 7 inches)
b Center mark
c Large frame embroidering area
18 cm × 13 cm (7 inches × 5 inches)
d Embroidering area for optional border embroidery
frame
18 cm × 10 cm (7 inches × 4 inches)
e Embroidery area for optional quilt embroidery
frame
15 cm × 15 cm (6 inches × 6 inches)
f Medium frame embroidering area
10 cm × 10 cm (4 inches × 4 inches)
g Embroidery area for optional small embroidery
frame
2 cm × 6 cm (1 inch × 2-1/2 inches)
h Embroidery area for optional border embroidery
frame
30 cm x 10 cm (12 inches x 4 inches)
i Grid lines
c
Press .
