Sterlco SSL and SSIL Series Hopper Loaders User Manual
Page 59
SSL/CSL and SSIL/CSIL Series Sight Glass Hopper Loaders
59
GASKET SELECTION
Figure 16: Typical SSIL/CSIL Series Sight Glass Hopper Loader - Exploded View
Item Quantity
Part
no.
Description
52A
1
W00012559
GSKT, THRT, EPT, BLACK, 4”, STD TEMP
52B
1
W00018024
GSKT, THRT, SILICONE, ORANGE, 4”, HI-TEMP
52C
1
W00016136
GSKT, THRT, NEOPRENE, WHITE, 4”, STD, TEMP (FDA)
