53
Figure 13: SSL/CSL 03 Series Hopper Loader Parts List
Refer to Figure 12 on the previous page for parts location .
Item Quantity Part no. Description
1 1 A0556521 FLG, MT, ADPT
2 1 A0553741 CONE, WELD, 6” ID, SSTL
3 1 A0556534 FLTR, FLAT, CLOTH, 6” OD
4 1 A0556513 CVR, WELD, 6” ID, SSTL
5 1 A0541543 GSKT, SILC, SGLS
6 SEE VOLTAGE OPTIONS
7 1 A0541036 BOX, GANG, SGL, 4X2X2, UL
8 1 A0541037 BOX, GANG, SGL, CVR, BLNK, GSKT
9 1 A0003254 WSHR, REDUC, 75˚ X .50” STEEL
10 1 A0003217 CDUT, NIP, ½” REGAL, #791
11 1 A0548359 PLUG, HEYCO, BLK, 5/B, #2663
12 3 A0541039 CORD, GRIP, ½”, .270-.480 #3231
13 1 A0556820 GSKT, U-CHNL, N PRN, .38 X .20 X .05W
14 1 A0541038 BOX, GANG, PLU, ½” NPT, UL
15 1 A558805 SW, ASSY, NC, LVL SNSR
16 1 A0558503 FLAP, DISCH, SS
17 4 W00002373 WSHR, FLAT, WI 3/16”, 100 PCS/3
18 2 W00016426 NUT, STOP, ¼-20, PLD
19 2 A0553718 SCR, SHC, SS, ¼-20 X ¾
20 2 A0556622 SCR, CAP, HEX, SOC, HD, 10-32X 1/2
21 1 A0559402 SCR, FLAT, CSLINK, 10-32X3/8, NYLOC
22 1 A0556544 CVR, SHRD, MTR
23 1 A0555771 NIP, S.S. 3/8” X 1˚ CLS
24 1 A0555770 NIP, S.S. 3/8” 3˚ LONG
25 1 A0555769 FTG, SS304, EL, 90, 3/8
26 3 A0533900 NUT, RIVET, STL, 1D-32, FLUSH
27 10 W00017594 HOSE, FLEX, CLR, VINYL, 1.5”
28 SEE VOLTAGE OPTIONS
29 2 W00001917 CLP, HOSE, DIX332, 1.56-2.50
30 1 A0560901 FLTR, SRL/I-1.0, POLY, FELT, GLAZED
31 1 A0505648 GROM, BLK, 0.5625X0.25X
32 1 A0533933 PICK, MATL, AL, SGL TUBE 1.5”
33 7 A0536966 CONN. WIRE NUT, IDEAL #AO-A1
115 VAC Options
34 .16 A0535193 TBG, HTSHRNK, 0.75ID, O.81 OD, 48” L
6 1 A0544850 MTR, 115V,2-STG,LAMB,11B212-00
36 1 A0544850 ASSY,CNTRL,SER 1,115
37 1 A0555792 SPLC, BUTT, PANDUIT, #PSN 16-M
28 1 A0556547 VLV, SOL, 3/8”, #JSF8210G1, 120V
39 1 A0558085 CORD, CONN, FEMALE, 33” GRAY
40 1 A0558086 CORD, CONN, MALE, 9”, GRAY
41 1 A0556087 CORD, CONN, MALE, 33” BLACK
42 1 A0558088 CORD, CONN, FEMALE, 9”, BLACK
