SSL/CSL and SSIL/CSIL Series Sight Glass Hopper Loaders
Figure 15: Typical SSL Series Hopper Loader Parts List, Version 1
Refer to Figure 14 on the previous page for parts location.
Item Model No. Quantity Part no. Description
1 SSR/SSL11 1 A0563505 CONE, WELD, 9” DIA.
2 SSR/SSL 1 A0563536 ASSEMBLY, FLAP/SUPPORT
3 SSL 06-11 1 A0556504 TUBE, INLET/OUTLET, 1-1/2”
4 SSR/SSL 1 A0563514 SWITCH, REED, MAG, SPDT
5 NPT 1 A0560919 ACCUMULATOR, 3/8”
6 SSR/SSL 1 A0563513 GASKET, THROAT, SEAL, FIBER
7 SSR/SSL 1 A0563510 FLANGE, 12” DIA., MOUNTING, MLD THROAT
8A SSR/SSL 1 A0563517 THROAT, 4” DIA., SILC
8B SSR/SSL 1 A0563543 THROAT INSERT, 4”, SS
9 SSR/SSL 1 A0563520 RING, 4” THROAT, SS
10 SSR/SSL 1 A0563512 WEIGHT, 4” FLAP VALVE
11 SSR 06-11 1 A0553728 O RING, SILICONE, 2.234 IDX 0.139CS
12 SSR/SSL 06-45 1 A0563516 BRACKET, J BOX
13 4 X 2 X 2 1 A0541036 BOX, SINGLE GANG
14 4 X 2 1 A0541037 COVER, BOX, SINGLE GANG
15 SSR06-11 1 A0556821 GASKET, D CHANNEL, 10” DIA.
16 1 A0541039 CORD GRIP, ½”, 0.170-0.430
17 NPT 1 A0541038 PLUG, BOX, GANG, ½”
18 1 A0003254 WASHER, REDUCER, .75’ X .5”
19 NPT 1 A0003217 NIPPLE, CONDUIT, ½”
20 1 A0548359 PLUG, NYLON, 5/8”
21 3 A0563700 SCREW, ¼” 20 X 1 , HEX, SER, FLANGE
22 2 A0563701 SCREW, ¼” 20 X ¾ , HEX, SER, FLANGE
23 1 A0563515 MAGNET, REED SWITCH ACTUATOR
24 1 A0563703 RIVET, 1/8” CLOSED, DOME HEAD
25 SSR/SLC 1 A0563533 VENT, LOUVER, 1” DIA.
26 SSR LOADERS 1 A0556514 COVER, 9” ID SSTL, CSL 06-11
27 3 A0556517 BOLT, J, 10-32 X 5.25L
28 1 W00020081 MOTOR, VACUUM, 120 VAC, 3 STAGE
29 SSTL 3 079.030100.00 FITTING, NIPPLE, 3/8” CLS.
30 SSTL 2 083.00303.00 FITTING, NIPPLE, 3/8” ELBOW
31 SSTL 1 A0555772 FITTING, NIPPLE, 3/8” X 4”
32 1 A0541543 GASKET, SILICONE, 3.75 OD X .188 THICK
33 1 A0556547 VALVE, SOLENOID, 3/8”, 115 VAC
34 SSL/SSIL06-11 1 A0565929 FILTER, POLY GLAZED
35 10 FT. W00017594 HOSE, FLEX, 1.5”, CLEAR VINYL
36 2 W00001917 CLAMP, HOSE, 1.5”-2.5”
37 1 A0533933 WAND, PICK UP, 1.5” ALUMINUM
