Sterlco SSL and SSIL Series Hopper Loaders User Manual
Page 30
30
SCROLL
SCROLL Key
Press the
SCROLL
SCROLL key to display:
• available menus when the controller is in Standby mode.
• operations screens such as batch counter and SPV settings when the
controller is operating.
S
START/STOP
START/STOP/SELECT/SET Key
Press the
S
START/STOP
START/STOP/SELECT/SET key to:
• start the hopper loader
• stop the hopper loader
• select parameters from menu screens
• set parameters
Series One Plus Controller Indicators
60
LED Screen
The red LED screen is a four-character alphanumeric display. It displays system statuses,
menus, and variable values for operating the hopper loader.
VACUUM
VACUUM Indicator
The VACUUM indicator lights when the unit is in Vacuum mode.
MATERIAL "A"
MATERIAL “A” Indicator
The MATERIAL “A” indicator lights when the Material A port is open.
