SSL/CSL and SSIL/CSIL Series Sight Glass Hopper Loaders
58
Figure 15A: Typical SLC Series Hopper Loader Parts List, Version 2
Refer to Figure 14 on the previous page for parts location.
Item Quantity Part no. Description
1 1 A0563504 CONE, WELD, 9” DIA., SSR/SSL/CSL06
1 A0563505 CONE, WELD, 9” DIA., SSR/SSL/CSL11
1 A0535506 CONE, WELD, 14” DIA., SSR/SSL/CSL23
1 A0563507 CONE, WELD, 14” DIA., SSR/SSL/CSL45
2 1 A0556504 IN/OUT, SSR 06-11. AL, 1.50
2 1 A0559449 INLET/POUTLET, 1 ½”, SSR 23-45
3 1 A0560919 ACCUMULATOR, 3/8” NPT
4 2 A0563513 GASKET, THROAT, SEAL, SSR/SSL/CSL
5 1 A0567621 FLANGE, MTG., 12” DIA., SSL/CSL 03-45
6 1 A0556546 ORNG, SIL, 3.234 ID. X 0.139 THK
7 1 A0563516 BRACKET, J BOX, SRC/SLC 02-16
8 1 A0541036 BOX, SINGLE GANG, 4 X 2 X 2
9 1 A0541037 COVER, BOX, SINGLE GANG, 4 X 2
10 1 A0565925 FILTER, SSL/CSL/ I-02/04, POLY, GLAZED
10 1 A0565930 FILTER, SSL/CSL/ I-08/16, POLY, GLAZED
11 4 A0541039 CORD GRIP, ½”, .0.120 – 0.470
12 1 A0541038 PLUG, BOX, GANG, ½” NPT
13 1 A0003254 WASHER, REDUCER, .75” X .5”
14 1 A0003217 NIPPLE, CONDUIT, ½” NPT
15 1 A0548359 PLUG, NYLON, 5/8”
16 1 A0556514 COVER, WELD, 9” ID SSTL, SSL/CSL06/11
16 1 A0565254 COVER, WELD, 14” ID SSTL, SLC23/45
17 3 A0556517 BOLT, J, 10-32 X 5.25L
18 1 W00020081 MOTOR, VACUUM, 115V
1 W00020082 MOTOR, VACUUM, 230V
1 W00020083 MOTOR, SPARE BRUSHES, 115V
1 W00020176 MOTOR, SPARE BRUSHES, 230 V
19 3 079.03010.00 FITTING, NIPPLE, 3/8”, CLS., SSTL
20 2 083.00303.00 FITTING, NIPPLE, 3/8”, ELBOW, SSTL
21 1 A0566970 FITTING, NIPPLE, 3/8” X 6”, SSTL, SSR23-45
22 1 A0541543 GASKET, SILICONE, 3.75 OD X .188 THICK
23 1 SEE CHART VALVE, SOLENOID, 3/8”
24 1 A0567620 ASSEMBLY, 4” ANGLED THROAT S.S, SSL/CSL 02-16
25 1 A0533925 SWITCH, REED, MAG, NO
26 2 A0567628 SCREW, BTNHD PHILLIPS, #6-32 X ½ LG. S.S
27 2 FT. W00000890 HOSE, RUBBER, BLK, ¼” X 1/16”
28 1 A0533924 MAGNET CERAMIC
29 1 A0567627 SCREW, FLTHD, PHILLIPS, #6-32 X ½” LG. S.S
30 1 A0567624 VENT, LOUVER, 2” DIA. SSR/SSL/CSL
31 10’ W00017594 HOSE, FLEX, 1.5”, CLEAR VINYL
32 2 W00001917 CLAMP, NOSE, 1.5” – 2.5”
33 1 A0533933 WAND, PICK UP, 1.5” ALUMINUM
34 3 A0069197 NUT, STOP, PLD, 10/32
45 2 A0003215 CA, TIES, STD, 75” BUNDLE, 18#
46 1 W00018618 SCR, 10-32 X ½” , SELF TAPPING
47 7.5” A0102623 WIRE, 600V, GRE/YLW, 18GA
48 1 A0535118 TBG, NPRN, 80-DUR, 5.O” OD X 0.94 WALL
49 1 A0535193 TBG, HTSHRNK, 0.75 ID, 0.81 OD, 48” L
50 2 A0003236 FEMAL SPADE TERM—SIZE 14
51 3 W00017962 SCR, SHC, ¼-20 X 5/8, W/PATCH
