Sterlco SSL and SSIL Series Hopper Loaders User Manual
Page 14
14
F
igure 3:
SSL Series Dimensions, Specifications, and Maximum Machine-Side Throughput
American Standards
Capacity
Dimensions in inches
cu.
ft.
A B C D E F
0.1
7.0
173/8” 63/8”
12”
13/4” 63/8”
0.2
211/8” 51/2”
12” 4” 91/8”
0.4
271/8” 111/2”
12” 4” 91/8”
0.8
30 ¼”
10 ½”
12”
4”
141/8”
1.6
5.75
36 ½”
17 ¾”
12”
4”
14 1/8”
Metric Standards
Capacity
Dimensions in cm
liters
A B C D E F
2.8 17.8
44.1
16.2 30.5 4.4 16.2
5.6 53.7
14.0
30.5 10.1 23.2
11.3 68.9
29.2
30.5 10.1 23.2
22
77
27
12
10.1
36
45
14.6
93 45 12 10.1 36
c
5/16”/0.313” (8.0 mm) -diameter holes; two (2) places equally spaced.
d
5/16”/0.313” (8.0 mm) -diameter holes; four (4) places equally spaced.
e
1/4”/0.250” (6.3 mm) -diameter holes; six (6) places equally spaced;
J is standard mounting hole pattern.
SSL Series Specifications
Model
Hopper capacity
Full-load amps
Inlet size range
Shipping weight
no. cu.
ft.
liters
lbs.
Kg
(FLA)
inches mm
lbs. Kg
SSL03 0.1 2.8 3.5
1.5
11
1½” 38 mm
47
22
SSL06 0.2 5.6 7.0
3.1
11
1½” 38 mm
65
30
SSL11 0.4 11.3
14.0
6.3
11
1½” 38 mm
67
31
SSL23
0.8
22
28
12.7
10
1 ½”
38 mm
75
34
SSL45
1.6
45
56
25.4
10
1 ½”
38 mm
80
36
SSL Series Maximum Machine-Side Throughput
Twelve (12) -foot (3.66 m) vertical 1½” OD (approx. 38 mm) flex hose; pellets @ 35 lbs./cu. ft. (560 Kg/cu. m)
Model Non-Proportioning
c
Proportioning
number lbs./hr. Kg/hr. lbs./hr. Kg/hr.
SSL03 150 68
Not available
SSL06 500 227
400 182
SSL11 1,000
454
800
364
SSL23 1,500
680
1,200
544
SSL45 1,700
771
1,350
612
c
Maximum throughput beside-the-press loading; includes 12-foot (3.6 m) vertical lift.
We are committed to a continuing program of product improvement. Specifications, appearances, and dimensions are subject to
change without notice.
