MBW473_MANUAL_E_V2.0 3
2 Quick Start
This section guides you through the set-up and the first steps using your 473. It is a summary and
should be used as a general overview and reference only. Do not use it as a substitute for the remain-
der of the manual. To understand your instrument thoroughly, please read the other sections carefully.
2.1 Unpacking
The 473 is delivered in a custom-fit foam-lined Peli 1550 transport case.
The following items are included in the case:

473 Dew Point Mirror

SH2 or RP2 measuring head (as ordered)

Temperature probe PT(100)
o The RP2 is supplied with a Ø3 x 30 mm PRT and a 0.5 m cable for extended connection
between the probe and the measuring head.
o The SH2 is supplied with a Ø2.1 x 100 mm PRT and a 0.5 m cable to connect the probe
to the measuring head and a 3 m cable to connect the probe directly to the back panel of
the instrument.

2.5 m power cable

2 m measuring head cable
 Gas connections 6mm or ¼” Swagelok (SH2 only)

Operation manual

Calibration certificate
Before starting, carefully remove these items from the case and visually check for any signs of dam-
age. If you are missing any item or find them damaged, please call the manufacturer or your local
supplier. Make sure that the power rating on the back label corresponds to your power supply specifi-
cation.
