Hoyles Redimon v3 Monitor User Manual
Dimensions, Redimon, A b c d

Dwg No: 60136 Oct 2011
Redimon is a latching monitor unit which fully monitors two
lengths of
to give independent alarm and fault
conditions. An End of Line resistor is fitted at the remote end of
each length of
. Pressing the
creates a
short circuit which will be detected as an alarm condition. If the
becomes disconnected in any way a fault condition
is generated. The Redimon requires 12 volts dc and provides
volt free changeover contacts for both alarm and fault. A Reset
button is provided.
Panic Strip
Panic Strip
Panic Strip
Panic Strip
Redimon can also be used to create a double pole EOL circuit
for any
momentary action normally open device. E.g. Push button.
Redimon is supplied with two 6k8 end of line resistors fitted
to the terminals AB and CD for test purposes. If only one
length of
is being monitored one of these
resistors should be left in either AB or CD terminals and the
other terminals used for the
.
Panic Strip
Panic Strip
Any other type of non-latching open circuit button or switch
could be wired across Panic Strip circuits to complement
the system as in Panic Strip 2 shown below.
Under normal circumstances the GREEN LED will be illuminated to show that power is on and the circuits are healthy. When
either
is operated the RED LED will illuminate and the alarm relay will change over. If either of the
circuits becomes disconnected the RED and GREEN LEDs will alternate and the fault relay will operate, this will restore
when the circuit has been repaired. To reset the
from an alarm condition press the Reset button.
Panic Strip
Panic Strip
Panic Strip
Dimensions in mm
Dimensions
12 Volts dc power
45ma max
Alarm output
Fault output
Panic Strip Type 3
Panic Strip Type 3
E.O.L 6k8
E.O.L 6k8
v3
Redimon
Latching monitor unit for Panic Strip
Use these changeover contacts to connect to the personal attack circuit of your intruder alarm.
Use these changeover contacts to connect to the tamper circuit of your alarm
11 - 14 volts dc at all times. Quiescent current 30ma Max current 45ma
ALARM
OUTPUT
NO
NO
COM
RELAY 1
RELAY 2
COM
NC
NC
FAULT
OUTPUT
T1
T2
TAMPER
SWITCH
6K8 Terminating resistors
Panic Strip
Type 2
Panic Strip
Type 3
Panic Strip
Type 3
Panic Strip
Type 2
These contacts are rated @ 30vdc 1A
Optional open circuit
non-latching push button
A B C D
NOTE
Panic Strip
SHOULD NEVER BE
CONNECTED DIRECTLY TO MAINS
VOLTAGE CIRCUITS.
IT IS ONLY RATED FOR SAFE WORKING
ON 43 VOLTS MAXIMUM.
T1 and T2 are normally closed. Opening this circuit will cause a fault
until the circuit is closed again. If wired as shown, removing the unit
cover will cause a fault to be indicated, until the cover is replaced.
T. 01744 886600 F. 01744 886607 E. [email protected] W. www.hoyles.com
Hoyles Electronic Developments Ltd
87.0
18.0
18.0
8
7
.0
v3
Redimon Monitor
Press to Reset
v3
Redimon Monitor
Press to Reset
Mode 1 operation - Single push
