1. Set SW 1 down for 10 VDC excitation or up for 5
VDC excitation. By default the CSG110 is set to 10
VDC at FUTEK.
2. Set the gain DIP switch (SW3) to the appropriate
gain level. By default the gain is set with switch 4 up
for a 2 mV/V sensor. (Utilize our online gain setting
Excel sheet on the FUTEK CSG110 support page to
find the appropriate gain DIP switch setting for your
sensor’s mV/V output.)
3. With the sensor and CSG110 completely connected
apply the 14 to 26 VDC power to the CSG110.
4. With no load on the sensor adjust the Zero potenti-
ometer until the output voltage is as close to 0 VDC
as possible.
5. With a known load placed on the sensor adjust the
Span potentiometer to as close to the appropriate
output level as possible. For example, 10 VDC for a
full load output.
6. Remove the load and reconfirm the zero load output,
and then reapply the known load and re-confirm the
span output.
Voltage Setup Steps
IMPORTANT NOTE: Do not connect the device to the power supply when the power supply is already on.
Note: Adjusting the Span will affect any system calibrations.
Adjusting zero will not affect calibration.
FUTEK’s online calibration tool allows you to
retrieve a summary of your sensor’s calibration data:
http://www.futek.com/calibrationData.aspx
