16
3 For FSH03546: Min. Power Supply is 12.5 VDC
4 Only for sensitivity of 1 mV/V or greater
5 Only for sensitivity of 1.5 mV/V or greater
VERSIONS
ITEM # BANDWIDTH OUTPUT
FSH01449 1 kHz
±5 VDC, ±10 VDC, 0–20 mA,
4–20 mA, 0–16 mA , 5–25 mA
FSH03546 3 1 kHz ±5 VDC, ±10 VDC
QSH00602 4 10 kHz
±5 VDC, ±10 VDC, 0–20 mA,
4–20 mA, 0–16 mA , 5–25 mA
QSH01498 5 25 kHz
±5 VDC, ±10 VDC, 0–20 mA,
4–20 mA, 0–16 mA , 5–25 mA
FSH03676 1 kHz
0–2.5-5 VDC , 0–5–10 VDC, 0–10–20 mA,
4–12–20 mA
Specifications
