FUTEK CSG110 (JM-2A / JM-2AD)-Series - Manual (Page 14)

14
DIP Switch 5, 6, and 7: Current Setting
• The voltage output from the CSG110 is passed
through a current conversion phase. As a result the
current output range is based on the voltage output
level, (Input Range), from the CSG110.
DIP Switch Description
CURRENT SETTING
SW5 SW6 SW7 Input Range Output Range
▼ ▼ ▼ 0–10 V 4–20 mA
▼ ▼ ▲ 0–10 V 5–25 mA
▲ ▼ ▼ 0–10 V 0–16 mA
▲ ▼ ▲ 0–10 V 0–20 mA
▼ ▲ ▼ 0–5 V 4–20 mA
▼ ▲ ▲ 0–5 V 5–25 mA
▲ ▲ ▼ 0–5 V 0–16 mA
▲ ▲ ▲ 0–5 V 0–20 mA
