Sensor DB9 Assembly
MALE DB9 CONNECTOR (SUPPLIED)
Top Cover
Nuts
DB9 Screws
Cover Screws
Set Screw
Bottom Cover
DB9 Male
Washer Covers
Information about your sensor, including
a spec sheet with wiring, can be found
on our website (www.futek.com). You
can find it by using the search feature
to search by the sensor serial number,
model number, or item number. Also, a
wiring calculator listing the connections
to the CSG110 is available at
http://www.futek.com/wirecode.aspx
