The CSG110 has no output or low,
non-changing output.
1. Confirm the power to the CSG110 is between 14 and
26 VDC.
2. Confirm there is not a short on the sensor side to
the CSG110. Using a voltmeter, the resistance can
be confirmed in the sensor ±Excitation and ±Signal
connections for any possible shorts.
3. When utilizing a current output, the current will only
flow positive — which means a negative output from
the sensor may result in a non-changing current
output from the CSG110, or a slight decrease in the
CSG110 output.
Troubleshooting Tips
Note: See the FUTEK website for an offset CSG110 to shift the
zero to accomodate a bidirectional output for current.
For more CSG110 support, please visit:
http://www.futek.com/csg/support.aspx
