F-20-TF-L, pg. 7 of 30
Mounting The Sensor
(Mounting hardware not included with sensor)
3. Tubing Connections
CAUTION : DO NOT FLOW ANY GAS THROUGH A LIQUID
FLOW SENSOR OR FLOW METER. THIS WILL DAMAGE THE
MICRO-TURBINE ASSEMBLY AND VOID THE WARRANTY.
All tubing must be clean and without crimps, burrs or scratches.
Only use the fittings factory installed on the unit. If the fittings are removed
the calibration of the unit may be effected and leaking may occur. If
different fittings are required please contact Dwyer Customer Service for
assistance.
When connecting the sensor to the tubing a wrench should be used to stop
the fitting rotating in the sensor body. Take care not to over tighten the
fittings or leaking may occur.
Connecting and tightening the Fittings
