Operating the monitor, Programming mode, Operating the monitor 14 – Badger Meter B3000 User Manual
Page 14: Programming mode 14
Compact Digital Flow Monitor, Model B3000
Page 14
March 2014
OPERATING THE MONITOR
The monitor has three modes of operation referred to as the Run, Programming, and Extended Programming modes
2
1
Battery
Indicator
Alarm
Activation
Rate
Units
Totalizer
Units
Totalizer
Multiplier
Total
Rate
Communications
Indicator
Figure 13: Display annunciators
To access the program mode, momentarily press and then release MENU until the first programming screen is displayed The
extended programming mode is entered by pressing and holding MENU until the first programming option appears After
programming the display with the necessary information, a lock out feature is available to prevent unauthorized access or
changing of the meter’s setup parameters
Programming Mode
COM
1
2
J1
S1
Menu
S4
Enter
S3
Up
S2
Down
COM
1
2
12
1
Figure 14: Keypad detail
