Device Variables
There are thirteen device variables as defined in the table below Device variables can be accessed with universal
command #9:
No.
Name
Classification
Units
0
Flow Rate
66
USER UNITS
1
Flow Velocity
67
m/s
2
T1/T+
68
USER UNITS
3
T2/T-
68
USER UNITS
4
T3/Tn
68
USER UNITS
5
Relative Flow Rate
81
%
6
Flow Rate
66
m
3
/s
7
T1/T+
68
m
3
8
T2/T-
68
m
3
9
T3/Tn
68
m
3
10
PS
68
m
3
11
PS
68
USER UNITS
12
Power Loss Totalizer
70
Seconds
Dynamic Variables
Four dynamic variables are supported Dynamic variables can be accessed with universal command #3 The assignment to
dynamic variables is fixed and is defined in the table below
No.
Name
Classification
Units
PV – Primary Variable
Flow Rate
66
USER UNITS
SV – Secondary
Variable
T1/T+
68
USER UNITS
TV – Tertiary Variable
T2/T-
68
USER UNITS
FV – Fourth Variable
T3/Tn
68
USER UNITS
Device Status
HART defined device status information is available Only those bits supported by the M2000 are listed in the table below All
other bits will be set to 0
Bit
Description
Comments
0
PV Out of Range
Set if the primary variable is exceeding the sensor limits
1
Non PV Out of Range
Not Used
2
PV Output Saturated
Set if the primary variables analog loop current exceeds the limits of 4 mA and 20 mA
3
PV Output Fixed
Set if the daughterboard is configured for multi-drop mode and the polling address is
non-zero When set current is fixed at 4 mA
4
More Status Available
Set when alarm or failure is detected Refer to command #48 for further information
5
Device Reset
Set at power-up or on reset of the meter
6
Configuration Changed
Indicates when M2000 configuration has been changed This bit can be cleared by
Universal command #38
7
Field Device Malfunction
Set when there is failure of the M2000 that prevents flow measurement
