Meter Measurement Settings
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
25 USER Flow Unit UINT16 DS 175/176 (Read/Write)
26 USER Volume Unit UINT16 DS 177/178 (Read/Write)
27 USER Unit Multiplier UINT16 DS 179/180 (Read/Write)
28 USER Full Scale Velocity [m/s] FLOAT32 DS 181/182 (Read/Write)
29 USER Full Scale Flow [User Units] FLOAT32 DS 173/174 (Read/Write)
30 USER Low Flow Cutoff [%] FLOAT32 DS 183/184 (Read/Write)
31 USER Flow Direction UINT16 DS 185/186 (Read/Write)
32 USER Damping Factor [s] UINT16 DS 187/188 (Read/Write)
Digital Input
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
33 SERVICE Digital Input: Input Operation UINT16 DS 190/191 (Read/Write)
34 FIRMWARE Digital Input: Status UINT16 DS 192 (Read)
Analog Output
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
35 SERVICE Analog Customer Offset 4 MA [A] FLOAT32 DS 193/194 (Read/Write)
36 SERVICE Analog Customer Offset 20 MA [A] FLOAT32 DS 195/196 (Read/Write)
37 FIRMWARE Analog Output Current [ A ] FLOAT32 UN 2/3 - (Read /Read)
38 SERVICE Alarm Mode UINT16 DS 197 (Write)
39 NONE Fixed Current Mode FLOAT32 UN 6/7 (Read/Write)
Output #1
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
40 SERVICE Output #1: Pulses Per Unit [User Units] FLOAT32 DS 200/201) Read/Write)
41 SERVICE Output #1: Pulse Width [ms] UINT16 DS 202/203 (Read/Write)
42 SERVICE Output #1: Flow Alarm Minimum [%] UINT16 DS 204/205 (Read/Write)
43 SERVICE Output #1: Flow Alarm Maximum [%] UINT16 DS 206/207 (Read/Write)
44 SERVICE Output #1: Output Mode UINT16 DS 208/209 (Read/Write)
45 SERVICE Output #1: Output Operation UINT16 DS 210/211 (Read/Write)
Output #2
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
46 SERVICE Output #2: Pulses Per Unit [User Units] FLOAT32 DS 200/201 (Read/Write)
47 SERVICE Output #2: Pulse Width [ms] UINT16 DS 202/203 (Read/Write)
48 SERVICE Output #2: Flow Alarm Minimum [%] UINT16 DS 204/205 (Read/Write)
49 SERVICE Output #2: Flow Alarm Maximum [%] UINT16 DS 206/207 (Read/Write)
50 SERVICE Output #2: Output Mode UINT16 DS 208/209 (Read/Write)
51 SERVICE Output #2: Output Operation UINT16 DS 210/211 (Read/Write)
