Empty Pipe
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
116 ADMIN Empty Pipe Calibration [Volts] FLOAT32 DS 233/234 (Read/Write)
117 FIRMWARE Empty Pipe Measure Value [Volts] FLOAT32 DS 237 (Read)
118 ADMIN Full Pipe Calibration [Volts] FLOAT32 DS 235/236 (Read/Write)
119 SERVICE Empty Pipe Mode UINT16 DS 231/232 (Read/Write)
Control Commands
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific
UN = Universal)
120 NONE Command Action Request UINT16 DS 244 (Write)
121 SERVICE Flow Simulation SINT16 DS 240/241 (Read/Write)
Security
No.: Write Security Register Name Register Type
HART Command Support
(DS = Device Specific UN =
Universal)
122 FIRMWARE Security Status UINT16 DS 243 (Read)
123 FIRMWARE Random Value UINT32 DS 247 (Read)
124 NONE Remote Login UINT32 DS 242 (Write)
M-Series® M2000 HART® Bi-Directional Communication Protocol Data Access
Page 20 December 2012
