Meter Status Register
Meter status is a status variable accessible over MODBUS that identifies the error state of the M2000 The HART daughterboard
shall query this MODBUS register and report status through the usage of Universal Command #9 and #48 Below is a table that
defines the meter status register Unused bits are not listed in the table and are always set to 0
Bit Description
0 Detector Error
1 Empty Pipe Error
2 Full Scale Flow Error
3 Totalizer Rollover Error
4 Totalizer Rollover Status
5 Flow Simulation Status
6 Reserved
7 ADC Interrupt Error
8 ADC Range Error
Universal Command #0 – Read Unique Identifier
Command #0 has particular status information that requires definition Below is a table that defines byte 16 of the response,
Extended Field Device Status
Bit Description
0 Maintenance Required - Set when Meter Status bits 0, 1, 3, 4, 7, or 8 are set
1 Alert State - Set when Meter Status bits 2,5,or 6 are set
Universal Command #9 – Read Device Variables with Status
Command #9 has particular status information that requires definition Below is a table that defines the device variable status
byte coding Only those defined in the table below can be observed
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Description
Process
Data
Status
Limit
Status
Reserved – Always 0
1 1 X X 0 0 0 0 Good Data – M2000 is without error and all measurements are proper
0 0 X X 0 0 0 0
Bad Data – M2000 is with error and measurements are not relating to actual
flow
Bad data is considered when “additional device status” indicates an error condition Refer to Universal Command #48 Warning
conditions are considered good data
