7
Operation
Mode Operation Selection
Depending upon the type of application, the DT-5TXR/DT-5TS offers different modes of operation; these modes and
their functions are:
Select the mode of operation as follows:
1. Press and hold the MODE button for approximately 3 seconds; “0” will begin flashing until one of the five modes
(see table above) appears on the display.
2. Each time one of the lower buttons (NUMERIC, NEGATIVE SIGN/DECIMAL POINT, BACKSPACE) is pressed, the
display will scroll through these modes as indicated below:
3. Press the SET button to store the mode of operation and exit.
MODE N O I T C N U F
-01- RPM or rate measurements
-02- Elapsed time measuring / monitoring
-03- Process time measurement
-04- Flow rate measurement (used only in Japanese market)
-99- Self-test (see “Self-Test” section under “Set-Up”)
Setting Mode Parameters
Modes -01-, -02- and -03- have several parameters that must be selected and programmed into the DT-5TXR/DT-5TS.
In addition, there are also function settings to further customize the DT-5TXR/DT-5TS.
NOTE: Because the flow rate measurement mode (-04-) is only used in the Japanese market, it is not covered in this
manual. Contact Shimpo for additional information if necessary.
NOTE: If a mistake is made entering any number, simply press the BACKSPACE button to erase the last digit on the
primary display.
Mode -01- (RPM or Rate Measurement)
The following parameters must be set in mode -01- so that the DT-5TXR/DT-5TS will display the correct readings:
DISPLAY MEANING
9 9 9 9 - 1 n o it ul o v e r r e p s e s l u P 1 _ _ 0001 1 ppr
2 Sensing U M P R p to 9999 9 _ 01000 1000 RPM
0 0 0 1 0 0 0 1 9 9 9 9 9 9 – 1 0 0 0 0 . 0 s ti n u y al p si D 3
4
Update time 0.2, 0.5, 1.0, 2.0, 5.0, 10, 1 5, 30, 60 seconds _ 1.0 _ 1 second
5 Display “Hold” after input signal ceases 0.1 – 150 seconds _ _ 006.0 6 seconds
z H k 2 0 . 0 , 0 0 1 , 0 3 , 0 1 r e tl if t u p n I 6 _ 10 _ 10 kHz
FACTORY SETTING
RANGE DESCRIPTION PARAMETER
