Important Safety Precautions Standard Accessories
If any damage is apparent, do not unpack the panel
meter. Notify the shipping carrier immediately for
damage claim instructions. Refer to the label to confirm
model number ordered and record serial number for
future reference.
Items included with the DT-5TXR or DT-5TS are:
• Mounting adapter, 2 pieces (attached)
• Mounting screw, 2 pieces (attached)
• Decal sheet
• Front button protective cover (attached)
Features and Benefits
The DT-5TXR/DT-5TS panel meter offers many features and
benefits including:
• Accepts a wide range of ppr (1-9,999) to
accommodate any sensor commonly found in the
field
• Wide range of AC voltage input (85 – 264 VAC 50/
60 Hz) eliminates duplicity of models or changing
of transformers
• Scalable; able to measure in various units
• Standard 1/8 DIN mounting enables easy mounting
while saving time
• Accepts modules (DT-5TXR only) which provide
different types of outputs, i.e. analog voltage,
analog current (4-20 mA), relay closures (set points),
BCD output and others for
recording purposes or data analysis
Never use wet hands when connecting or
disconnecting a sensor or checking the unit.
Always use the correct voltage (AC type: 85-
264VAC, DC type: 9-35VDC).
Do not position the signal wires and power
cord near each other.
Remember to check terminal connections, as
they may become loose due to vibration.
Do not use or store unit in extreme
temperatures; normal operating temperature
is 32-113ºF (0-45ºC).
Do not use or store unit in oily, dusty, or high
humidity areas.
Do not use chemicals to clean the case; use a
damp, soapy cloth.
Do not operate the unit in a location where
electrical noise, static electricity or excessive
vibration is present.
Confirm that the unit is turned OFF when
connecting or disconnecting the unit to a
sensor.
