SHIMPO DT-315P User Manual
Page 9

* In delay mode, the correct delayed angle can only be obtained with a stable
input signal.
If the input signal frequency exceeds the upper and lower limits, the alarm mark
will be displayed and the strobe will stop flashing.
IN RPM DISPLAY MODE
When the input signal exceeds 500Hz, the over mark will light.
When the input signal is lower than 1.6Hz, the under mark will light.
IN DEG, MSEC DISPLAY MODE
When the input signal exceeds 60Hz, the over mark will light.
When the input signal is lower than 3.3Hz, the under mark will light.
