SHIMPO DT-315P User Manual
Page 12
(3) Remove the reflector and pull out the lamp base. Caution, do not pull
out the lamp glass directly.
(4) Do not touch the flash tube with fingers. Use a clean cloth. Press the
lamp base to the socket in the proper direction to install the new
lamp.
(5) Important: In order to maintain protection against water, be sure to
mount the reflector in the center. Fix the reflector on the former
position and fix the protective window with fingers. Use a clean cloth.
Press the lamp base to the socket in the proper direction to install the
new lamp.
