4. OPERATION
EXTERNAL SIGNAL MODE
Interior signal mode INT
Mode can be changed alternatively by
SIG switch.
External signal mode EXT
Tune mode rpm display
Delay mode
Deg display
Ms Conversion display
Mode can be changed in order by MODE
switch.
1. Connect signal wires with main body of the instrument after soldering
the wires with connectors.
2. Firmly plug power cord into a 120VAC (USA) or 230VAC (Europe)
single phase outlet.
