5
OPERATION
22
OPTISENS OAM 2080
www.krohne.com 08/2010 - MA OPTISENS OAM 2080 R01 en
Operation
5.1 Start-up and general remarks for configuration
The start-up procedure of the sensor begins when both the converter and the sensor are
supplied with power and the electrical connection between the devices is established. First of all
the converter performs a self-test, then the identification of the sensor starts. During this
process, which may take up to 30 seconds, the converter display shows a rotating line between
the header and the time on the first line of the display. Afterwards a wizards appears and you
have to connect the sensor to an empty slot. For further information refer to the next section.
5.2 LED indication
There are three LEDs (red, yellow, green) on the front door of the meter which indicate its
operation status.
INFORMATION!
•
Connect the converter and the meter before starting-up! The MAC 080 converter must have
the program version 3.1 or higher, otherwise it cannot work together with the meter. If the
converter has a lower program version, always contact the manufacturer for an update!
• You are not able to make any changes to the settings until the converter has recognized the
sensor! You have to configurate the meter with the help of the converter and its display and
buttons.
Operation status Red Yellow Green
Starting up. On On On
Standby, waiting for next sampling cycle. Off Off On
Configuration mode. Off Off Blinking
Taking sample. Off Blinking Off
Configuration error (something in the
parameter settings stops the device from
operating).
Blinking Blinking Blinking
Operation error (mechanical or electrical fault
that stops the device from operating).
On Off Off
