In Europe you can connect the flush hose according to the following drawing. In the USA there
are hoses available with a fixed male connector that you can screw-in directly):
If you do not need the flushing function, you can disable it via the sensor menu. For further
information refer to
Menu for OAM 2000 sensor on page 31.
Plug the flush hose onto the ¼" NPTmale thread under the lower right hand corner of the
enclosure.
