VoIPMaster 260W
46
• Service Name: This item is for identification purposes. If it is required, your ISP will
provide you the information. Maximum input is 20 alphanumeric characters.
• IP Address: Specify an IP address allowed to logon and access the router’s web server.
Note: IP 0.0.0.0 indicates all users who are connected to this router are allowed to logon
the device and modify data.
• Authentication Protocol Type: Default is Chap (Auto). Your ISP will advise you
whether to use Chap or Pap.
• Always on: If you want the router to establish a PPPoE session when starting up and to
automatically re-establish the PPPoA session when disconnected by the ISP.
• Connect to Demand: If you want to establish a PPPoE session only when there is a
packet requesting access to the Internet (i.e. when a program on your computer attempts
to access the Internet).
• Idle Timeout: Auto-disconnect the broadband firewall gateway when there is no activity
on the line for a predetermined period of time.
• Detail: You can define the destination port and packet type (TCP/UDP) without checking
by timer. It allows you to set which outgoing traffic will not trigger and reset the idle timer.
• RIP: RIP v1, RIP v2, and RIP v2 Multicast. Check to enable RIP function.
• MTU: Maximum Transmission Unit. The size of the largest datagram (excluding
mediaspecific headers) that IP will attempt to send through the interface.
• TCP MSS Clamp: It is enabled by default. All TCP traffic routed through the interface
will be examined. If a TCP SYN (synchronize/start) segment is sent with a maximum
segment size larger than the interface MTU (Maximum Transmission Unit), the MSS
option will be rewritten in order to allow TCP traffic to pass through the interface without
requiring fragmentation
Advanced Options (PPPoE)
• LLC Header: Selects encapsulation mode, true for using LLC or false for using VC-Mux.
• Create Route: This setting specifies whether a route is added to the system after IPCP
(Internet Protocol Control Protocol) negotiation is completed. If set to enabled, a route
will be created which directs packets to the remote end of the PPP link.
• Specific Route: Specifies whether the route created when a PPP link comes up is a
specific or default route. If set to enabled, the route created will only apply to packets for
the subnet at the remote end of the PPP link. The address of this subnet is obtained
during IPCP negotiation.
• Subnet Mask: sets the subnet mask used for the local IP interface connected to the PPP
transport. If the value 0.0.0.0 is supplied, the netmask will be calculated from the class of
the IP address obtained during IPCP negotiation.
• Route Mask: Sets the subnet mask used by the route that is created when a PPP link
comes up. If it is set to 0.0.0.0, the subnet mask is determined by the IP address of the
remote end of the link. The class of the IP address is obtained during IPCP (Internet
Protocol Control Protocol) negotiation.
• MRU: Maximum Receive Unit. This is negotiated during the LCP protocol stage.
• Discover Primary / Secondary DNS: This setting enables/disables whether the
primary/secondary DNS server address is requested from a remote PPP peer using
IPCP. The default setting for this command is enabled.
• Give DNS to Relay: Controls whether the PPP Internet Protocol Control Protocol (IPCP)
can request the DNS server IP address for a remote PPP peer. Once IPCP has
discovered the DNS server IP address, it automatically gives the address to the local
DNS relay so that a connection can be established.
