KEPCO HSF 1500W Series (all models) Operator Manuals User Manual
Kepco, Operator’s manual, Model

IMPORTANT NOTES:
1)
This manual is valid for the following Model and associated serial numbers:
MODEL
SERIAL NO.
REV. NO.
2)
A Change Page may be included at the end of the manual. All applicable changes and
revision number changes are documented with reference to the equipment serial num-
bers. Before using this Instruction Manual, check your equipment serial number to identify
your model. If in doubt, contact your nearest Kepco Representative, or the Kepco Docu-
mentation Office in New York, (718) 461-7000, requesting the correct revision for your
particular model and serial number.
3)
The contents of this manual are protected by copyright. Reproduction of any part can be
made only with the specific written permission of Kepco, Inc.
Data subject to change without notice.
KEPCO
®
THE POWER SUPPLIER™
MODEL
OPERATOR’S MANUAL
KEPCO INC.
KEPCO, INC. ! 131-38 SANFORD AVENUE ! FLUSHING, NY. 11355 U.S.A. ! TEL (718) 461-7000 ! FAX (718) 767-1102
email: [email protected] ! World Wide Web: http://www.kepcopower.com
An ISO 9001 Company.
HSF 1500W
©2013, KEPCO, INC
P/N 228-1589-R3
HSF 1200W/1500W
POWER SUPPLY
HSF 1200W/1500W
POWER SUPPLY
SINGLE OUTPUT POWER SUPPLIES
SINGLE PHASE, POWER FACTOR CORRECTED
UNIVERSAL AC INPUT, OPTIONAL METER
HSF 24-50, HSF 36-42, HSF 48-32
HSF 24-50M, HSF 36-42M, HSF 48-32M
HSF 24-50C, HSF 36-42C, HSF 48-32C
Document Outline
- 1.1 Scope of Manual
- 1.2 Description
- FIGURE 1. RA 19-4C Rack Adapter I/O Connector
- TABLE 1. Rear Connector Pin Assignments
- TABLE 2. Output Ratings and Specifications
- FIGURE 2. Power Rating Vs. Temperature
- TABLE 3. Power Supply Ratings and Specifications
- FIGURE 3. Mechanical Outline Drawing Of HSF 1200W/1500W Power Supply
- 3.1 DIP Switch Configuration
- FIGURE 4. DIP Switch Configuration
- 3.2 Front Panel Access.
- 3.3 Keying
- FIGURE 5. Front Panel Controls, Indicators and Test Points
- 3.4 Output Voltage Control
- 3.4.1 Front Panel Voltage Control
- 3.4.2 Remote Voltage Control
- TABLE 4. Minimum Conditions for Relay, Meter and LED Operation
- FIGURE 6. DIP Switch Settings for Control of Output Voltage
- 3.5 Current Monitor (C and M Suffix only)
- FIGURE 7. Connections For Remote Voltage Control
- 3.6 Remote On-Off
- FIGURE 8. DIP Switch Settings for Using RESET button or Remote ON-OFF
- 3.7 Protection Circuits
- 3.7.1 Overvoltage And Overtemperature Protection
- 3.7.2 Overcurrent/Current Limit Setting and Protection
- 3.7.3 Fan Failure
- 3.7.4 Undervoltage
- 3.8 Alarm Settings
- 3.8.1 Visual Alarm.
- 3.8.2 Alarm Signals.
- 3.8.2.1 Internal Isolated Relay Alarm
- 3.8.2.2 Optically-Coupled Logical Alarm
- FIGURE 9. DIP switch settings for Optically Coupled Logical Alarm
- FIGURE 10. Output Alarm Circuit Optically Isolated
- FIGURE 11. ±PF Power Failure Optocoupler Timing Diagram
- 3.9 Retaining Latches
- FIGURE 12. Correct and incorrect Methods of Load Connection
