13.3 Troubleshooting table for displayed errors

Displayed errors

Code + Description

Cause

Solution

Remark

S01 (blocking error)

Open circuit from

temperature sensor T2

at bottom of the tank

Sensor is not (correctly)

connected

Connect the sensor lead to JP3

See the SGS electrical diagram

(17 "Appendices")

Damaged cable or

defective sensor

Replace the sensor

To replace the necessary parts, you must contact your installation

engineer

S02 (blocking error)

Open circuit in sensor 1

of temperature sensor

T

1

at the top of the

tank

(1)

.

Sensor is not (correctly)

connected

Connect the sensor lead to JP5

See the SGS electrical diagram

(17 "Appendices")

Damaged cable or

defective sensor

Replace sensor T

1

To replace the necessary parts, you must contact your installation

engineer

S03 (blocking error)

Open circuit in sensor 2

of temperature sensor

T1 at the top of the tank

(1).

Sensor is not (correctly)

connected

Connect the sensor lead to JP5

See the SGS electrical diagram

(17 "Appendices")

Damaged cable or

defective sensor

Replace sensor T

1

To replace the necessary parts, you must contact your installation

engineer

S04 (blocking error)

Open circuit from

dummy 1

Dummy is not

(correctly) connected

Connect the dummy sensor (dummy sensor 1 and 2) leads to JP4. See the SGS electrical diagram

(17 "Appendices")

Defective dummy

Replace the dummy sensor

To replace the necessary parts, you must contact your installation

engineer

S05 (blocking error)

Open circuit from

dummy 2

Dummy is not

(correctly) connected

Connect the dummy sensor (dummy sensor 1 and 2) leads to JP4. See the SGS electrical diagram

(17 "Appendices")

Defective dummy

Replace the dummy sensor

To replace the necessary parts, you must contact your installation

engineer

S06 (blocking error)
Open circuit from

temperature sensor S4

at bottom of storage

tank

Sensor is not (correctly)

connected

Connect the sensor lead to J14 (port 1 and 3) of the solar controller See the SGS electrical diagram

(17 "Appendices")

Damaged cable or

defective sensor

Replace the sensor

To replace the necessary parts, you must contact your installation

engineer
