Service program
78 Instruction manual SGS
12
is
• : SETTINGS SOLAR | QT SENSOR
12.8.7 Reading the energy contribution of
the solar heating system
This option enables you to read out how much energy
the solar heating system supplies. For this data to be
displayed, the installation must be equipped with a QT
sensor
(12.8.6 "Setting the QT sensor yes/no") .
3 values are reported on the display:
•
ACTUAL , actual energy: the amount of energy
currently being supplied.
• LAST 24hr , energy supplied over last 24 hours.
• TOTAL , total energy supplied since day 1.
Call up this menu as follows:
•
: SETTINGS SOLAR | CONTRIBUTION
12.9 Setting the central heating
configuration
Use this menu to specify whether a central heating
system is connected to the installation.
Note
This function is not yet available.
• : SETTINGS HEATING
QT SENSOR
YES
»NO
CONTRIBUTION
ACTUAL 00000 kW
LAST 24hr 00000 kJ
TOTAL 00000 Mj
SETTINGS HEATING
