Instruction manual SGS 71
gis
11.9 Deleting times from a week program
All switch-on/off times are shown sequentially in the
display. Assume that the switch-on/off times for the
appliance are programmed as in the figure.
To delete a period, proceed as follows:
1.
: WEEK PROGRAM | PROGRAM OVERVIEW.
Confirm with .
2. Scroll with to PROGRAM OVERVIEW.
Confirm with .
The display shows the menu for the week
program.
3. Scroll with to DELETE.
Confirm with .
To warn you that you are now working in the delete
sub-menu, the cursor is replaced with an
exclamation mark (!) and the period settings flash.
4. Scroll with to the day to be deleted. For
example, SU (Sunday) in the second period. See
the figure.
Confirm with .
5. The lines showing switch-on/off times are replaced
by the text DELETE BLOCK?. See the figure.
Confirm with
.
(or use to cancel)
The switching period has been deleted. You will return
now to the week program menu. The cursor points to
the first programmed period.
6. Scroll with to START OPERATION.
Confirm with .
The week program is active.
11.10 Extra period
Use an extra period when you either want to have the
appliance switch on and off for a certain period, either
without modifying the active week program, or without
taking the appliance out of the OFF mode (frost
protection active).
If the appliance is running under an "extra period",
then this is indicated in the display with the text
EXTRA
.
DAY TIME Tset
ON »SU 08:15 75ÉC P
OFF SU 12:45
ON SU 18:00 75ÉC P
OFF SU 22:00
....................
....................
OFF SA 23:59
INSERT
DELETE
START OPERATION
MENU
OFF
^»ON
È WEEK PROGRAM
WEEK PROGRAM
START OPERATION
^»PROGRAM OVERVIEW
È
DAY TIME Tset
ON !SU 08:15 75ÉC P
OFF SU 12:45
ON SU 18:00 75ÉC P
OFF SU 22:00
....................
....................
OFF SA 23:59
INSERT
DELETE
START OPERATION
DAY TIME Tset
ON !SU 18:00 75ÉC P
OFF SU 22:00
ON MO 00:00 65ÉC P
OFF MO 23:59
....................
....................
OFF SA 23:59
INSERT
DELETE
START OPERATION
DAY TIME Tset
ON ! DELETE
OFF BLOCK?
ON MO 00:00 65ÉC P
DAY TIME Tset
ON »SU 08:15 75ÉC P
OFF SU 12:45
ON MO 00:00 65ÉC P
OFF MO 23:59
....................
....................
OFF SA 23:59
INSERT
DELETE
START OPERATION
EXTRA
10:00 Monday 76ÉC
MO 11:15 Tset 75ÉC
PERIOD ACTIVATED
