SCANNER BOX HSB-001-1/2
USER MANUAL
2
2. SPECIFICATION
Model
Spec
HSB-001-1 HSB-001-2
High Voltage
Rating
5kV AC /6kV DC 5kV AC / 6kV DC
High Current
Rating
42 A --------------------------
Number of HV
Channel
8 channel 16 channel
Number of HC
Channel
8 channel --------------------------
System Interface
Scan interface to
GPT/GPI-700A Scan interface to
GPT/GPI-700A
Power Source AC115V, 230V±10% 50/60Hz
Operation
Environment
Indoor use, altitude up to 2000m.
Ambient Temperature 0℃ to 40℃.
Relative Humidity 80% (Maximum).
Installation category II
Pollution Degree 2
Storage temperature
& Humidity -10℃ to 70℃.
70% (Maximum).
Accessories
GHT-109 × 1(only for HSB-001-1),
GHT-110 × 1, GHT-108 × 1
Instruction manual × 1,
Dimension 320(L)×330(W)×130(H)
Weigh Approx. 6 kgs
SCANNER BOX HSB-001-1/2
USER MANUAL
3
3. PRECAUTIONS BEFORE OPERATION
3-1. Unpacking the instrument
The product has been fully inspected and tested before
shipping from the factory. Upon receiving the instrument,
please unpack and inspect it to check if there is any damage
caused during transportation. If any sign of damage is found,
notify the bearer and/or the dealer immediately.
3-2. Safety Notice
Checking the Line Voltage
The instruments can be applied with any kind of line voltage
shown in the table below. Before connecting the power plug
to an AC line outlet, make sure the voltage selector of the rear
panel is set to the correct position corresponding to the line
voltage. It might be damaged the instrument if connected to
the wrong AC line voltage.
WARNING. To avoid electrical shock the power
cord protective grounding conductor must be
connected to ground.
The equipment shall not be used for
measurements within category II, III and IV.
