Quick Reference

53

Synchronize phase

Synchronize phase

Track

CH2=CH1

CH1=CH2

Coupling

Frequency(Ratio or
Difference)

Frequency(Ratio or
Difference)

Amplitude & DC
Offset

Amplitude & DC
Offset

Dsolink

Burst

Waveforms

Sine, Square, Ramp

Sine, Square, Ramp

Frequency

1uHz~25MHz

1uHz~25MHz

Burst Count

1 to 65535 cycles or
Infinite

1 to 65535 cycles or
Infinite

Start/Stop Phase

-360 to +360

-360 to +360

Internal Period

1ms to 500s

1ms to 500s

Gate Source

External Trigger

External Trigger

Trigger Source

Single, External or
Internal Rate

Single, External or
Internal Rate

Trigger Delay

N-Cycle, Infinite

0s to 655350ns

0s to 655350ns

Frequency Counter

Range

5Hz to 150MHz

Accuracy

Time Base accuracy±1count

Time Base

±20ppm (23˚C ±5˚C) after 30 minutes warm
up

Resolution

The maximum resolution is:
100nHz for 1Hz, 0.1Hz for 100MHz.

Input Impedance

1kΩ/1pf

Sensitivity

35mVrms ~ 30Vms (5Hz to 150MHz)

Save/Recall

10 Groups of Setting Memories

Interface

USB (Host&Device)

Display

TFT

General Specifications

Power Source

AC100~240V, 50~60Hz

Power Consumption 25 W (Max)

Operating
Environment

Temperature to satisfy the specification : 18
~ 28˚C
Operating temperature :
0 ~ 40˚C
Relative Humidity:
< 80%, 0 ~ 40˚C
Installation category: CAT II

Operating Altitude

2000 Meters

Storage Temperature -10~70˚C, Humidity: ≤70%

Dimensions
(WxHxD)

266(W) x 107(H) x 293(D) mm

Weight

Approx. 2.5kg

Accessories

GTL-101× 2

Quick Start Guide ×1
CD (user manual + software) ×1
Power cord×1
