Quick Reference

37

Frequency Counter

Frequency Counter

Example: Turn on the frequency counter. Gate time: 1 second.

Output: N/A

Input:





rr

ountr

rr



1. Press UTIL, Counter

(F5).



ountr

2. Press Gate Time (F1),

and press 1 Sec (F3)
to choose a gate time
of 1 second.

atm



3. Connect the signal of interest to the Frequency

counter input on the rear panel.
