AFG-2225 Quick Start Guide

50

AFG-2225 Specifications

The specifications apply when the function generator is powered on
for at least 30 minutes under +18°C~+28°C.

AFG-2225 models

CH1

CH2

Waveforms

Sine, Square, Ramp, Pulse, Noise, ARB

Arbitrary Functions

Sample Rate

120 MSa/s

Repetition Rate

60MHz

Waveform Length

4k points

Amplitude
Resolution

10 bits

Non-Volatile
Memory

4k points

Frequency Characteristics

Range

Sine

1uHz~25MHz

Square

1uHz~25MHz

Ramp

1MHz

Resolution

1uHz

Accuracy

Stability

±20 ppm

Aging

±1 ppm, per 1 year

Tolerance

≤1 mHz

Output Characteristics

Amplitude

Range

1mVpp to 10 Vpp (into 50Ω)
2mVpp to 20 Vpp (open-circuit)
1mVpp to 5 Vpp (into 50Ω) for
20MHz-25MHz
2mVpp to 10 Vpp (open-circuit) for
20MHz-25MHz

Accuracy

±2% of setting ±1 mVpp
(at 1 kHz)

Resolution

1mV or 3 digits

Flatness

±1% (0.1dB) ≤100kHz
±3% (0.3 dB) ≤5MHz
±5% (0.4 dB) ≤12MHz
±10%(0.9dB) ≤25MHz
(sine wave relative to 1kHz)

Units

Vpp, Vrms, dBm

Offset

Range

±5 Vpk ac +dc (into 50Ω)
±10Vpk ac +dc (Open circuit)
±2.5 Vpk ac +dc (into 50Ω) for 20MHz-25MHz
±5Vpk ac +dc (Open circuit) for
20MHz-25MHz

Accuracy

2% of setting + 10mV+ 0.5% of amplitude

Waveform Output

Impedance

50Ω typical (fixed)
> 10MΩ (output disabled)

Protection

Short-circuit protected
Overload relay automatically disables main
output
