Display – GW Instek AFG-2225 Quick Start Guide User Manual
Page 16
AFG-2225 Quick Start Guide
14
Display
Soft Menu
Keys
Status Tabs
Parameter
Windows
Waveform
Display
Parameter
Windows
The Parameter display and edit window.
Status Tabs
Displays the current channel and setting status.
Waveform Display
Used to display the waveform
Soft Menu Keys
The function keys (F1~F5) beside the Soft Menu
keys correspond to the soft keys.
