MEASUREMENT
23
Bus Display Press Bus Display from the bottom
menu and Hex or Binary from the side
menu.
Range Hex, Binary
Event Table 1. Press Event Table from the bottom
menu.
2. Press Event Table from the side
menu to turn the event table On or
Off.
Event On, Off
3. To save the event table, press Save
Event Table.
Use the variable knob to scroll through the event
table.
I
2
C Serial Bus Interface
The I 2 C bus is a 2 wire interface with a serial data line (SDA) and
serial clock line (SCLK). The I 2 C protocol supports 7 or 10 bit
addressing and multiple masters. The decode software will trigger
on any of the following conditions: a start/stop condition, a restart,
a missing acknowledge message, Address, Data or Address& Data
frames. The I
2 C trigger can be configured for 7 or 10 bit addressing
with the option to ignore the R/W bit as well as triggering on a
data value or a specific address and direction (read or write or
both).
Panel operation 1. Insert each of the bus signals (SCLK, SDA) to
one of the oscilloscope channels.
