Appendix a, Zone types and action when activated, Appendix – Fire-Lite PS-Tools 5UD/10UD User Manual
Page 88: A 1 zone types and action when activated

5/10 Zone Panel
PS-Tools 07/2010
77
A
A
A
Appendix
This chapter lists the various zone types and action when activated, coding selections, and explains
the Two Stage Operation and Synchronized NAC operation.
Zone Types and Action When Activated
Zone Type
Action When Activated
Pull-Station
Fire Alarm
Waterflow
Fire Alarm Delayed (uses waterflow delay)
Waterflow Nonsilenceable
Fire Alarm (uses waterflow delay)
Combo
Fire/Supervisory (uses waterflow delay)
Combo AutoResettable
Supervisory
Fire/Supervisory AR, nonlatching (uses
waterflow delay)
2-Wire Detector
Fire Alarm
Normally Open Contact
Fire Alarm
Fire
Fire Alarm
Tamper
Supervisory
Supervisory
Supervisory, latching
Supervisory AutoResettable
Supervisory, nonlatching
Medic-Alert
Supervisory, latching
Hazard-Alert
Supervisory, latching
Tornado-Alert
Supervisory, latching
Proc-Mon
Piezo
Procmon-AutoResettable
Piezo, nonlatching
AC-Loss-Mon
Trouble
