5/10 Zone Panel
PS-Tools 07/2010
Version of Panel
PS-Tools helps to configure the five or ten zone (5/10) fire panel.
Related Documents
For more information about topics that are relevant to the subject of this manual, see the document
listed below:
Typographical Conventions
This document uses the following typographical conventions:
Panel Firmware Version
Programming Tool
5/10 Zones
PS-Tools 1.0 B1
Document Title
Contents
5/10 Zones (Document Id:
52626)
Installation procedures and
technical specifications for the
Fire Alarm Control Panel.
Style
What it represents
Example
bold
Menu titles, user interface literals
Double-click PS-Tools icon.
Buttons you click to perform actions
Click Exit to close the program.
Italic
Items you select
2-Wire Detector
Cross-reference within document
For more information, see
Configuring Fire Panel.
Cross-reference to chapters
See Getting Started.
