Fire-Lite PS-Tools 5UD/10UD User Manual
Page 37

28
5/10 Zone Panel
PS-Tools 07/2010
Configuring 5/10 Zones Fire Panel
Note
Event Codes are associated with the selected Communication Format. If the
Communication Format changes the Event Codes also change.
The zone type, zone location, and alarm verification options are configured in the
Input/Output Modules pane.
You must double click an Event Code to toggle its state.
In PS-Tools, 000 is reserved to indicate that Event Code is disabled.
Disabling an event code for one central station, disables the same event code
for the other central station automatically.
To configure the zone event codes
1.
Double click an Event Code to toggle its state.
2.
Click Next to continue with the configuration of event codes for the primary central station or
select Primary Central Station Continued in the left pane.
