P-047550-1385 ISSUE 4
Table 1. Division 2 Locations
Class Division Group Temp. Code
I 2 A, B, C, D T3C (160°C, 320°F)
II 2 F, G T6 (85°C, 185°F)
III T6 (85°C, 185°F)
Table 2. Replacement Parts
Catalog Number or
Component Part Number
Strobe tube 91B-ST
Lens 96-L(*)
*The letter in this position (A - amber, B - blue, C - clear, G - green, M -
magenta or R - red) signifies the color of the lens; for example, a red lens for
the 94DV2 series signal is 93-LR.
Figure 2. Strobe Tube Replacement
Figure 1. Conduit Mounting
