The catalog number 53D-GW AdaptaBeacon signal is an
in-rush current limited, DC-operated, rotating light. The
signal may be either conduit mounted or direct surface
mounted and is suitable for indoor installation. A hard-
ware kit is included with the signal for direct mounting
applications.

Specifications

Specifications

Specifications

Specifications

Specifications

d. Route the wiring from the required power source

for the signal (refer to the signal's label for the
voltage rating) through the center holes in the
mounting surface, gasket and base.

e.

Align the holes in the gasket with the holes in the
base. Insert the two screws with lockwashers
provided in the hardware kit through the
mounting holes inside the base and align the
screws with the rubber expansion plugs as shown
in Figure 2. Press the base firmly against the
mounting surface and tighten the screws.

3.

Using wire nuts (not supplied), connect one of the
signal's red wire leads to the incoming positive (+)
power source lead and the other to the outgoing
positive (+) power source for the next unit or an end-
of-line resistor. Connect one of the signals' white wire
leads to the incoming negative (-) power source lead
and the other to the outgoing negative (-) power source
for the next unit or an end-of-line resistor.

NOTE: Wire run must be broken at each unit for

electrical supervision.

Catalog

Dome

Lamp

Number

Voltage

Current

Replacement

Replacement

53DA-GW

24 - 28V DC

1.0A

52-LA

Cat. No. 1638

53DB-GW

24 - 28V DC

1.0A

52-LB

Cat. No. 1638

53DC-GW

24 - 28V DC

1.0A

52-LC

Cat. No. 1638

53DG-GW

24 - 28V DC

1.0A

52-LG

Cat. No. 1638

53DM-GW

24 - 28V DC

1.0A

52-LM

Cat. No. 1638

53DR-GW

24 - 28V DC

1.0A

52-LR

Cat. No. 1638

Installation

Installation

Installation

Installation

Installation

1.

Remove the screw in the clamp ring, remove the ring
and lift off the dome (Figure 1).

2.

Install the base using one of the following applicable
procedures.

Conduit Mounting

a.

Route the wiring from the required power source
for the signal (refer to the signal's label for voltage
rating) through a 1/2" NPT conduit (not supplied)
and through the conduit entrance hole in the base.

b. Install the base on the conduit.

Direct Surface Mounting

a.

Remove the two knockouts for the mounting
screws from the bottom of the base. See Figure 1
for the location of the knockouts.

b. Place the gasket provided in the hardware kit on

the mounting surface and mark the center of the
three holes in the gasket on the surface. Remove
the gasket and drill a 3/8" hole at each of the
marked positions.

c.

Install the two rubber expansion plugs provided
in the hardware kit into the two outer holes in
the mounting surface as indicated in Figure 2.

CAUTION

Ensure that power is disconnected before installing the
signal.

Maintenance

Maintenance

Maintenance

Maintenance

Maintenance

Lamp Replacement

1.

Replace the lamp as follows (Refer to Specifications
for the required lamp.):

a.

Disconnect power.

b. Remove the screw in the clamp ring and remove

the ring.

c.

Lift the dome off the signal.

d. Replace the lamp.

Cleaning

The dome should be periodically cleaned to maintain light
visibility. The dome may be cleaned with a soft cloth or
sponge using a mild detergent. Dry the dome thoroughly
before replacing.

CAUTION

Always disconnect power before disassembling the
signal.

P/N 3100633 ISSUE 2 © 2004

Cheshire, CT 06410 203-699-3300 (Ph)
203-699-3365 (Cust. Serv. Fax)
203-699-3078 (Tech. Serv. Fax)

Installation and Maintenance Instructions for the

Catalog 53D-GW AdaptaBeacon

®

Signal

CAUTION

Do NOT use abrasive materials or cleaners to clean the
dome.
